Box Semi-Trailer Manufacturer & Supplier



We supply enclosed box semi-trailers for general freight, distribution, parcel logistics, and commercial cargo transportation. Configurations can be specified by trailer length, internal cargo volume, axle arrangement, body panels, floor construction, suspension, and braking system.
For fleet operators, freight forwarders, distributors, and logistics companies, the key selection factors are usable cargo space, payload requirements, loading and unloading methods, road regulations, and compatibility with the tractor unit.





Specifications & Configurations

Technical Parameter

Standard Dry Freight Specification

Heavy-Duty Logistic Specification

Payload Capacity

30,000–40,000 kg, subject to configuration and legal limits

Up to 45,000 kg, subject to technical and regulatory confirmation

External Dimensions

Length: 13,000–16,200 mm; width: 2,500–2,600 mm; overall height: approximately 4,000 mm

Custom dimensions subject to vehicle design and local road regulations

Internal Volume

Reference range: 85–110 m3

Reference range: 90–120 m3

Main Chassis Beam

Beam height: 500 mm; web plate: 8–10 mm; top and bottom flanges: 14–16 mm

To be confirmed according to the selected chassis design

Chassis Material

Q345B or T700 high-strength structural steel, subject to material specification

Material grade and plate thickness to be confirmed

Axle Configuration

2 or 3 axles; 13T or 16T axle options; BPW or FUWA options

To be confirmed according to payload and operating requirements

Suspension

Mechanical leaf spring suspension, reference section 90 mm x 13 mm, or air suspension with lifting valve

To be confirmed according to the selected configuration

Side Walls

Corrugated steel panels, 1.2–1.5 mm, or pre-painted aluminum composite panels with internal vertical hat posts at approximately 450 mm spacing

Panel structure and reinforcement to be confirmed

Roof

One-piece stamped aluminum sheet or translucent FRP bonded to steel roof supports

To be confirmed according to the selected body design

Rear Doors

Double-wing cargo doors with galvanized cam-lock hardware and rubber weather seals

To be confirmed

Floor

2.5–3 mm checkered steel plate or 21 mm waterproof plywood with crossmember support

Floor material and load rating to be confirmed

Kingpin & Landing Gear

JOST 2-inch or 3.5-inch kingpin options; JOST D200T two-speed landing legs

Confirm kingpin size, mounting arrangement, and landing gear rating

Braking & Electrical

WABCO ABS option, dual-line pneumatic brakes, and 24V LED lighting; market-specific configurations available subject to confirmation

Braking and lighting configuration to be confirmed for the destination market



Applications



General Freight Transport

Enclosed cargo space for palletized goods, packaged products, boxed inventory, and other dry freight.

Parcel and Distribution Logistics

Suitable for freight movement between distribution centers, sorting hubs, warehouses, and regional delivery terminals.

Retail and Consumer Goods

Enclosed body construction for transporting packaged merchandise that requires protection from ordinary road dust and weather exposure.

Industrial Cargo

Can be configured for selected boxed equipment, spare parts, and packaged industrial goods, subject to floor capacity, loading access, and cargo dimensions.



Refrigerated Box Semi-trailer manufacturers



Customization Options

Dimension & Axle Layout: Tailored body lengths, widths, and axle spacings engineered to comply with regional axle-load legislations (e.g., North American bridge formulas or European weight directives).



Multi-Temp / Insulated Configurations: Optional XPS (Extruded Polystyrene) core insulation layer inside side panels and roof for temperature-sensitive cargo handling.



Floor Reinforcement: Choice of heavy-duty aluminum T-flooring or high-density composite wood flooring rated for fork-truck axle loading up to 7,000 kg.



Internal Cargo Security: Integration of E-track, logistic tracks, or cargo retention straps welded at multiple vertical heights along the interior posts.



Surface Coating & Branding: Customized polyurethane industrial topcoat color matching and custom corporate logo decals applied prior to delivery.



Quality Inspection & Manufacturing

Plate Cutting & Welding: CNC plasma cutting ensures precision dimensional accuracy. Main structural beams utilize automatic submerged arc welding (SAW) to maintain continuous, deep-penetration weld seams across high-stress zones.



Shot Blasting & Surface Prep: Complete chassis frames undergo automated centrifugal shot blasting (Sa 2.5 standard) to eliminate mill scale, rust, and surface impurities prior to painting.



Corrosion Protection: Application of two-layer anti-corrosive epoxy zinc-rich primer followed by a high-durability polyurethane topcoat, baked in a controlled curing chamber to resist road salt and chemical degradation.



Rigorous Factory Testing:

  • Load & Deflection Testing: Dynamic weight testing applied to chassis frames to measure camber retention and deflection limits under rated overload conditions.
  • Pneumatic & Seal Testing: Complete air-brake circuit pressure validation (leakage tests under 8 bar) and water-spray enclosure testing to verify absolute rear door and roof weather-sealing integrity.



Export, Delivery & Spare Parts

Logistics & Packaging

Flexible export dispatch options including containerized shipping (for disassembled/KD kits), flat-rack shipping, or Ro-Ro (Roll-on/Roll-off) vessel delivery for fully assembled trailers.

Documentation Support

Comprehensive export paperwork packages provided, including Certificate of Origin, commercial invoices, packing lists, and structured assembly/maintenance manuals.

Spare Parts Availability

Dedicated inventory of critical replacement assemblies—including brake chambers, suspension bushings, landing gear gearboxes, LED lamp assemblies, and door gasket seals—dispatched via air express to minimize fleet downtime.





FAQ



Q: What is the standard production lead time for a custom batch of box semi-trailers?

A: Standard production cycles range from 25 to 35 working days following drawing approval and deposit receipt, depending on customization complexity and batch volume.

Q: Can the internal dimensions and height be adjusted to meet specific regional bridge clearance limits?

A: Yes. Overall height, internal width, and gooseneck configurations are engineered to order to match local highway height and volume restrictions.

Q: What is the difference between corrugated steel panels and aluminum composite panels?

A: Corrugated steel panels offer maximum structural rigidity, impact resistance, and cost-effectiveness for heavy industrial freight. Aluminum composite panels reduce tare weight, improve payload capacity, and provide a smooth exterior surface ideal for fleet branding.

Q: How is the chassis protected against rust caused by winter road de-icing salts?

A: All primary chassis components undergo thorough shot blasting to Sa 2.5, followed by a multi-layer epoxy primer and chemical-resistant polyurethane topcoat system designed for high-salinity road environments.

Q: Are the braking and electrical systems compatible with international tractor units?

A: Yes. Trailers are equipped with standard ISO 7-pin electrical connectors, SAE/DOT-compliant LED lighting, and WABCO pneumatic braking systems compatible with standard North American and European prime movers.

Q: What warranty terms do you provide for structural frame components?

A: We provide a structural warranty covering main frame beams and load-bearing welds against manufacturing defects for a period of 12 months from the date of port arrival.

As one of the most professional box semi-trailer manufacturers and suppliers in China, we also support customized service. Please feel free to buy high quality box semi-trailer for sale here from our factory. For price consultation, contact us.
