Technical Specifications
|
Parameter |
Specifications |
|
Overall Dimensions (L×W×H) |
Standard: 13500×2950×3550mm (customizable upon request) |
|
Payload Capacity |
58-98 tons |
|
Deck Length |
Standard: 8800mm; Extendable up to 6m (optional) |
|
Deck Height |
1420mm (low center of gravity for enhanced stability) |
|
Axles |
3-5 heavy-duty axles (FUWA/BPW, 14-19 ton load per axle) |
|
Suspension System |
Mechanical suspension (standard); Air suspension (optional) |
|
Brake System |
WABCO dual-circuit pneumatic EBS with anti-lock function |
|
Kingpin |
2.0/3.5 inch (JOST brand, ISO 1161 compliant) |
|
Body Material |
High-tensile S690QL/Q345B steel |
|
Extending Mechanism |
Hydraulic-driven telescopic system with secure locking device |
Will It Fit My Project?
Yes. This telescopic low bed trailers works for most heavy‑transport jobs, whether you carry excavators, generators, wind turbine parts, steel beams, or containers. It adapts to different load lengths and weights, matching local road rules across markets. If you have special dimensions, tonnage, or local certification needs, we can customize it to fit your exact project.
Key Advantages
- Strong, durable main beam made from high‑strength steel for long service life and less deformation
- Telescopic design that quickly adjusts deck length without extra tools
- Low deck height for better stability, safer loading, and compliance with height limits
- Reliable braking, suspension, and world‑famous parts for consistent performance
- Simple structure that cuts maintenance time and operating costs
What Customers Say
"We've used this telescopic low bed trailers for over two years on construction jobs. It's stable, extends smoothly, and rarely needs repairs. Our team finds it easy to operate, and it has saved us time on every trip." – Heavy haul company, Africa
Company Strength & Export Capacity
We are a professional manufacturer with years of export experience, serving 50+ countries. We fully understand international transport rules, certification requirements, and port procedures. We have complete production, quality control, and logistics teams to support stable mass production and on‑time delivery.
Pricing & Cooperation
We offer factory direct prices based on axle count, load capacity, length, and accessories. Flexible terms include wholesale, customized orders, and bulk deals. We provide clear quotes and support trade terms like FOB, CIF, and CFR.
Packing & Shipping
Trailers are sprayed with anti‑rust paint and protected with plastic film. We use bulk shipping, RO‑RO, or flat rack containers based on your port and needs. We prepare all export documents for smooth customs clearance.
FAQ
What load capacity do you offer?
We normally make 40–100 ton models, and can customize higher capacity on request.
How long can the deck extend?
Standard extension is 2–6 meters; longer telescopic lengths are available for special loads.
Can you meet local certification rules?
Yes, we build to CE, DOT, or your country's standards and provide full documents.
Do you support after‑sales service?
We offer free online support, video guidance, and cost‑effective spare parts for years.
What payment terms do you accept?
We accept T/T, L/C, and other secure international payment terms.
Can you ship to my nearest port?
Yes, we arrange shipment to any main port worldwide and provide full shipping details.
