Key Product Advantages

Made from high‑strength steel with stable welding and anti‑corrosion painting for long service life
Lightweight frame boosts payload and cuts fuel costs
Works with 20ft, 40ft, and standard containers with secure twist locks
Simple design means fast loading/unloading and low maintenance
Stable suspension and braking for safe long‑distance hauling

Technical Specifications

Parameter	Details
Overall Dimensions (L×W×H)	12500×2550×1500mm (40ft model); 7800×2550×1450mm (20ft model) – customizable
Payload Capacity	20-45 tons (varies by axle configuration and container type)
Frame Structure	Ladder-type main frame, I-shaped longitudinal beams, crossbeam spacing optimized for container locking
Locking Devices	4-12 ISO-standard twist locks (adjustable, compatible with 20ft/40ft container corner castings)
Axles	2-4 heavy-duty axles (FUWA/BPW, 10-16 ton load per axle)
Suspension System	Mechanical leaf spring suspension (standard); Air suspension (optional)
Braking System	WABCO dual-circuit pneumatic EBS with ABS anti-lock function
Kingpin	2.0/3.5 inch (JOST brand, ISO 1161 compliant)
Material	Main frame: High-tensile Q345B/S700MC steel; Locking components: High-strength cast steel
Self-Weight	6-8 tons (40ft model); 4-5 tons (20ft model)
Tire Specification	12R22.5 heavy-duty radial tires (4-8 tires based on axle count)

Company & Export Strength

We are a professional manufacturer with years of export experience, fully capable of mass production and global delivery. Our quality control follows international standards, and we provide complete export documentation including COC, packing list, and commercial invoice. We have long-term cooperation with reliable shipping lines to ensure on-time, safe delivery to any port.
